LASERS Ultraviolet Lasers Visible Lasers Infrared Lasers Low Noise Lasers Single Frequency Lasers Q-Switched Pulsed Lasers Fiber Lasers Line Output Lasers RG & RGB Laser Systems RG Lasers 532 / 635 RG Lasers 532 / 650 RG Lasers 532 / 671 RGB Lasers 445 / 532 / 635 RGB Lasers 445 / 532 / 650 RGB Lasers 445 / 532 / 671 RGB Lasers 473 / 532 / 635 RGB Lasers 473 / 532 / 650 RGB Lasers 473 / 532 / 671 YGB Lasers 445 / 532 / 593 YGB Lasers 473 / 532 / 593 Custom-built RG RGB YGB Lasers Laser Modules Laser Module Brackets Laser Module Power Supplies Laser Pointers Custom-built Laser Products LASER ACCESSORY PARTS PRECISION OPTICS CRYSTALS RG LASER SYSTEMS YELLOW LIGHT OUTPUT SYSTEMS Specifications Products Code SSL - RG635 - XXXX - XXM - D Wavelength [ nm ] 532 635 / Total Output Power [ mW ] 300, 500, 800, 1000 Output Power Rate [ % ] 45 55 / Operating Mode CW Transverse Mode TEM00 TE00 / Operating Temperature [ ºC ] 10 - 35 Storage Temperatures [ ºC ] -10 - 45 Warm-up Time [ minutes ] < 15 Power Stability [ Over 4hours ] 5%, 3% Beam Diameters At The Aperture [ mm ] ~ 4.5 Beam Divergence [ mrad ] < 5.0 Point Stability After Warm-up [ mrad ] < 0.1 Modulation [ TTL or Analog Alternative ] Standard 10KHz, Up to 40KHz need request TTL & Analog both in one laser system need request Laser Head Dimensions [ mm ] 220 [ L ] × 90 [ W ] × 70 [ H ] Power Supply Dimensions [ mm ] 105 [ L ] × 55 [ W ] × 55 [ H ] Adapter Dimensions [ mm ] 100 [ L ] × 56 [ W ] × 34 [ H ] Working Voltage [ VAC ] 85 - 245 Laser Gross Weight [ kg ] 2.3 Cooling Way TEC & Air Expected Lifetime [ hours ] > 10000 Warranty Time [ year ] 1 Lead Time [ ARO ] 1 - 3pcs 5 - 10pcs < 20pcs < 2weeks < 3weeks < 4weeks         Last Update Time: 2024. 05. 15     Note:     1. Laser price including "laser head" and "power supply".   Sanctity Laser not sell "laser head" or "power supply" individually.       2. Operation Instruction For This Laser:             3. Notes For TTL Modulation: TTL     Analog       4. Notes For Warranty and Safe:       5. Explain for every laser specification please check here:       6. More request for the products please contact to our Customer Service Team:             Our Promise:   • 24 Hours Reply Reply the Email within 24hours [ work day ]. • No Mini Order No minimum quantity per order. • Fast Delivery Fast and Exact delivery time for standard products. • Best Quality Best quality depend on best quality material, high-tech and long test time & way. • Low Repair Rate Laser Repair Rate low than 18‰. • Different Plug Different plugs for different countries and special test for different power source. • Safe Transaction 20Years working for develop laser products, never leave or stop.
